Инженерный чертеж
Основные параметры
| Model No. | V60A 14S | Power Cable | Silicone wire-red/black -14AWG-160mm |
| Size | 77*33*19mm (L*W*H) | Signal Cable | Shielded cables-Black-OD4.2-5C -300mm-JP-3P*2-Black blank white-green yellow gray |
| Weight(Incl. cables) | 85g | Encoder cables | Shielded cables-Black-24AWG-5C -300mm-M6 aviation connector |
| Motor Cable | Silicone wire-orange-16AWG-60mm | Protocol | PWM/CAN |
| Support Voltage | 18~60V (6~14S) | BEC | NO |
| Continuous Current | 30A | Throttle Pos. Range | 1040-1940 |
| Peak Current(<10s) | 60A | Throttle Refresh Frequency | 50-500HZ |
| Standby Consumption | ≤50mA@48V | Throttle Response Speed | 300ms |
| Производитель: | T-Motor |
