T-Motor AM850 KV195 Бесколлекторный двигатель с тягой 19.7 кг для 3D самолетов 84"-89"

27756.48 грн.

Купить

Рассрочка online

Нашли дешевле?
Получите цену ниже!

Код товара: lgr93

Доставка в течение 2 недель.

AM850 IS
DESIGNED FOR
84"-89" 3D
PLANES

Break free from traditional
constraints, so you will release
from your heavy planes and feel
lightweight and agile instantly

NON-DESTRUCTIVE
REPLACEMENT FOR
CONVENIENT INSTALLATION

Fixed with the same mounting plate as the
gas engine for quick installation

THE WORLD’S TOPPILOTS HAVE
REPEATEDLYCALIBRATED
CTHE POWERCURVE AND HAND FEEL

Enabling rapid control over delicate 3D flights

HOW FAST ARE
YOUR HANDS?
HOW ACCURATE
ARE YOUR FINGERS?

AM850’s zero-latency and precise
tracking allows you to show off
your skills easily

EQUIPPED WITH THE
AMZ 23*10 CARBON FIBER
PROPELLER

Instantly releasing19.7kg of continuous thrust High response, high burst,let you show off your skills easily

QUICK INSTALLATION
COMFORTABLE ADAPTION

Technical Drawing

Specification

Test Item	KV195	Weight (Incl. Cable)	1025g
Motor Dimensions	Φ90*145mm	Internal Resistance	9mΩ
Lead	160mm	Configuration	24N28P
Shaft Diameter	10mm	RatedVoltage(Lipo)	10-12S
Idle Current(10V)	5.7A	Peak Current(180s)	75A
Max. Power(180s)	3780W	Recomended ESC/Propeller	AM216A/AMZ23*10

Test Data

Type	Propeller	Throttle	Voltage (V)	Current (A)	Power (W)	RPM	Torque (N*m)	Thrust (g)	Efficiency (g/W)	Operating Temperature (℃)
AM850 KV195	T23*10	30%	50.75	12.04	611.21	3467	1.07	3708	6.07	/
		35%	50.70	15.29	775.22	3810	1.30	4517	5.83
		40%	50.64	18.88	955.94	4127	1.53	5341	5.59
		45%	50.58	22.50	1137.98	4414	1.75	6149	5.40
		50%	50.53	26.72	1350.29	4698	2.00	7031	5.21
		55%	50.45	31.57	1592.35	4995	2.28	8014	5.03
		60%	50.36	37.54	1890.45	5309	2.60	9135	4.83
		65%	50.26	44.38	2230.59	5629	2.95	10377	4.65
		70%	50.14	53.33	2674.01	5997	3.39	11907	4.45
		75%	50.00	62.93	3146.70	6325	3.82	13376	4.25
		80%	49.85	73.41	3659.51	6642	4.27	14901	4.07
		85%	49.66	85.77	4259.53	6955	4.77	16524	3.88
		90%	49.46	98.65	4878.64	7232	5.26	17989	3.69
		95%	49.18	117.31	5768.72	7577	5.96	19353	3.35
		100%	49.14	125.49	6165.93	7711	6.25	19789	3.21
Note: Motor temperature is motor surface temperature @100% throttle running 3mins. (Date above based on benchtest are for reference only, comparion with that of other motor types is not recommended.)
AM850 KV195	T24*10	30%	50.75	12.43	630.70	3262	1.20	3984	6.32	/
		35%	50.69	15.91	806.34	3591	1.46	4869	6.04
		40%	50.64	19.86	1005.85	3906	1.74	5797	5.76
		45%	50.58	24.14	1221.03	4203	2.02	6761	5.54
		50%	50.48	29.61	1494.69	4520	2.35	7926	5.30
		55%	50.38	35.61	1794.11	4829	2.70	9128	5.09
		60%	50.27	43.28	2175.51	5166	3.12	10524	4.84
		65%	50.13	52.56	2634.89	5517	3.60	12137	4.61
		70%	49.97	63.20	3158.28	5862	4.11	13828	4.38
		75%	49.79	75.11	3739.78	6188	4.66	15577	4.17
		80%	49.63	87.74	4354.49	6486	5.19	17280	3.97
		85%	49.40	101.94	5036.29	6785	5.78	19080	3.79
		90%	49.22	116.69	5743.76	7053	6.34	20694	3.60
		95%	48.92	135.52	6629.69	7330	7.01	21532	3.25
		100%	48.83	145.11	7086.45	7459	7.33	22036	3.11
Note: Motor temperature is motor surface temperature @100% throttle running 3mins. (Date above based on benchtest are for reference only, comparion with that of other motor types is not recommended.)

Packing List

Производитель:

Ligpower

Тэги: AM850 KV195 Motor 19.7kg Thrust for 84"-89" 3D Planes T-Motor купить AM850 KV195 Motor 19.7kg Thrust for 84"-89" 3D Planes T-Motor обзор
